Vacuum Bare Board Loader


The Bare Board Loader is used for automatically loading unpopulated boards at the beginning, or in the middle of a PCB assembly line. The bare boards are lifted one by one from the stack by vacuum and are gently lowered onto the belt segment, ready for the
downstream machine.


  • Omron PLC Control system.
  • FUJI button, or touch screen operation options available.
  • By pass mode selectable.
  • Flexible suction design, position adjustable.
  • Sucking stability improved by using single
    vacuum generator system.
  • Width adjusting system by hand crank. Electrical width adjustment available on request.
  • SMEMA compliant.
  • CE certified
  • Safety cover is standard for CE conveyors
  • Automatic width adjustment
  • FOLLOW ME system compatible


Model IE-CT/CB-350A-SL IE-CT/CB-400A-SL IE-CT/CB-460A-SL
Power Supply AC 110/220V ±10V, 50/60HZ
Air Supply 5kgf/cm2
PCB Size 400x(50 – 350)mm 460x(50 – 400)mm 535x(50 – 460)mm
Transfer Height 900 ±20mm
PCB Direction left to right or right to left(option)
Machine Size 700x735x1250mm 750x785x1250mm 800x835x1250mm
Control Panel 1. Touch Screen (T), 2. FUJI Button (B)
