Multifunction PCB Buffer

Application

The Multifunction PCB Buffer is used to buffer PCB’s in LIFO or FIFO mode. “Pass-through” mode may be selected so that PCB is transferred by it, or “Automatic” mode may be selected so that this machine is used as a PCB buffer.

Machines with Hermes protocol to meet the requirements of Industry 4.0



Features

  • Servo motor, Omron PLC control system, touch screen operation.
  • 3 operative modes: FIFO (first in first out), LIFO (last in first out), pass through.
  • 24 pcs PCB’s storage capability.
  • Electrical width adjustment.
  • Direction from left to right or right to left(optional).
  • SMEMA compliant.
  • CE certified
  • Safety cover is standard for CE conveyors
  • Automatic width adjustment
  • FOLLOW ME system compatible

Specification

Model IE-CT-350A-BL IE-CT-400A-BL IE-CT-460A-BL
Power Supply AC 110/220V ±10V, 50/60HZ
Air Supply 5 bar
PCB Size 350x(50 - 250)mm 460x(50 - 330)mm 535x(50 - 390)mm
Buffer Capacity Max. 24 PCBs at pitch 1
Transfer Height 900 ±20mm
PCB Direction left to right or right to left (option)
Machine Size 500x885x1650mm 610x935x1650mm 610x995x1650mm
